Bredal Gödningsspridare

F-Serien gödningsspridare från Bredal.

F2 och F4 är burna spridare 1500-4000 liter.

F8 och F10 är bogserade spridare 5,7 – 11,6 kubik

Kategorier: Lantbruksmaskiner, Växtskydd & Gödselspridare

Gör en intresseanmälan

eller

Kontakta en säljare nära dig

Technical data:


	F2 1500	F2 2500	F2 3000	F2 3200	F2 4000
Capacity	1,500 litres	2,500 litres	3,000 litres	3,200 litres	4,000 litres
Spread unit	SPC4500-1	SPC4500-1	SPC4500-1	SPC4500-1	SPC4500-1
Hopper length	1520mm	1520mm	1520mm	1520mm	1520mm
Hopper width	2400mm	2400mm	2400mm	3000mm	3000mm
Loading height*	1480mm	1745mm	1870mm	1950mm	2080mm
Net weight	from 825 kg**	–	–	–	–

* The loading height is measured from a spreader standing on the ground
** The basic weight is an F2 1500 with no optional equipment – the weight, therefore depends on the model and the equipment selected.

Technical data:


	F4 1500	F4 2500	F4 3000	F4 3200	F4 4000
Capacity	1,500 liters	2,500 liters	3,000 liters	3,200 liters	4,000 liters
Spread unit	SPC4500-1	SPC4500-1	SPC4500-1	SPC4500-1	SPC4500-1
Hopper length	1520mm	1520mm	1520mm	1520mm	1520mm
Hopper width	2400mm	2400mm	2400mm	3000mm	3000mm
Loading height*	1500mm	1765mm	1890mm	1970mm	2100mm
Net weight	from 950kg**	–	–	–	–

* The loading height is measured from a spreader standing on the ground
** The basic weight is an F4 1500 with no optional equipment – the weight, therefore depends on the model and the equipment selected.

Technical data:


	F8	F10
Capacity	5.70 m3	6.60 m3
with hopper extension, 23cm	7.50 m3	8.60 m3
with hopper extension, 50cm	–	11.60 m3
Net weight	3200kg	3800kg
Overall length	6600mm	6600mm
Spread unit	SPC4500-2	SPC4500-2
Hopper length	3916mm	4016mm
Hopper width	2000mm	2200mm
Loading height, min.	2475mm	2385mm
Loading height, max.	2975mm	3155mm
Minimum width, outside wheels	2250mm	2250mm
Maximum width, outside wheels	2800mm	2800mm
Biggest possible wheel diameter:	Ø 2100mm	Ø 2100mm
